PULS CS3.241 DIN-Rail Power Supply, 24VDC 10A 1-Phase
PULS
$225.00
Free Lifetime Technical Support - Expert product, application, and troubleshooting assistance from our technical team for the life of your product.
The PULS CS3.241 is a compact 24 VDC, 3.4 A single-phase DIN-rail power supply designed to provide reliable DC power for industrial control and automation systems. Part of the PULS DIMENSION C-Line, the CS3.241 combines a space-saving design with high efficiency, wide-range AC input, and robust electrical performance for a wide range of industrial applications.
At just 32 mm wide, the CS3.241 helps conserve valuable control cabinet space while delivering up to 80 W of output power. Its wide 100-240 VAC input range simplifies installation across different power systems without requiring input voltage selection, while an efficiency of up to 89.8% helps reduce energy consumption and heat generation.
The CS3.241 is designed for reliable operation in demanding environments, with a -25°C to +70°C operating temperature range and full power available from -25°C to +60°C. High immunity to transients and power surges, low electromagnetic emissions, and a broad range of international approvals make it well suited for industrial automation and control applications.
Key Features
- 24 VDC output, 3.4 A, 80 W
- Single-phase power supply
- Wide 100-240 VAC input range
- Compact 32 mm width for space-saving installation
- Up to 89.8% efficiency
- DIN-rail mounting
- NEC Class 2 compliant
- Full power from -25°C to +60°C
- Operating temperature range of -25°C to +70°C
- Screw terminal connections
- High immunity to transients and power surges
- Low electromagnetic emissions
- CE, UL, and C-UL approvals
- Part of the PULS DIMENSION C-Line family
